MPU-1012
  TECHNICAL-STANDARD

 Temperature:  -40～70℃
 Withstand Voltage:  AC 250V(50Hz)/min
 Rated Load:  DC 30V 0.1A
 Actuating Force:  40～150G
 Contact Resistance:  ≤0.03Ω
 Life:  100000次
 Insulation Resistance:  ≥100MΩ
