XCK-015-2-01
  TECHNICAL-STANDARD

 Temperature:  -30～70℃
 Withstand Voltage:  AC 1500V(50HZ)/min
 Rated Load:  DC 250V 10A
 Actuating Force:  3～20N
 Contact Resistance:  ≤0.03Ω
 Life:  5O00次
 Insulation Resistance:  ≥100MΩ
